Note: 1 .Before purchasing the product, please check whether your motorcycle connector is compatible with my product connector. Mounting: For Suzuki Boulevard C50 2005-2010 For Suzuki Boulevard M50 2005-2018 For Suzuki Boulevard M90 2009-2010 For Suzuki Boulevard C90 2005-2012 For Suzuki Boulevard C109R/T 2008-2015 For Suzuki Boulevard M109R/R2 2006-2010 For Suzuki DL650 V-Strom 2004-2011 For Suzuki DL1000 V-Strom 2004-2013 For Suzuki GSF1250 Bandit 2007-2010 For Suzuki GSF1250 N/NA Bandit 2007-2009 For Suzuki GSF1250 S/SA Bandit 2007-2016 For Suzuki GSX1400 2004-2009 For Suzuki GSX650F 2008-2010 For Suzuki GSX-R600 2004-2005 For Suzuki GSX-R750 2004-2005 For Suzuki GSX-R1000 2003 For Suzuki Intruder C800 2005-2010 For Suzuki Intruder M800 2005-2015 For Suzuki Intruder C1500 2005-2012 For Suzuki Intruder M1500 2009-2015 For Suzuki Intruder C1800R 2008-2015 For Suzuki Intruder M1800R 2006-2010 For Suzuki Intruder M1800R2 2008-2010 For Suzuki RMX-450Z All Years For Suzuki RM-Z250 (EFi model) All Years For Suzuki RM-Z450 (EFi model) All Years For Suzuki SV650 2003-2014 For Suzuki SV1000 2003-2009 For Suzuki VL800 Intruder Volusia 2005-2010 For Suzuki VL1500 Intruder 2005-2012 For Suzuki VLR1800 2008-2015 For Suzuki VZ800 Marauder 2005-2015 For Suzuki VZ1500 2009-2015 For Suzuki VZR1800 2006-2010 (If you encounter any questions, please be sure to contact me first, please do not leave negative comments first, I very much hope to answer your questions, thank you) Description: Condition:100% Brand New Color of Light Source: Red , green,blue Item Name: Speed Gear Display Indicator Size: Approx. 4cm*4cm*4cm/1.57inch*1.57inch*1.57inch Package List: 1 x Motorcycle Gear Indicator/Bracket(as shown in the picture) Feature: Shows current gear number Indicates current gear from 1 to max of 6. as well as a neutral indicator. Auto programming Compatible with all motorbikes,four wheeler,bikes etc. will fit anything with a shift lever Detects the current gear faster than other gear indicators that use speedometer/tachometer signal. Display can be mounted anywhere Foreword: Congratulations on your purchase of a gear position indicator. is the most advanced gear position indicator on the market today. This product will fit all For Suzuki fuel injected (FI)motorcycles which have on-board Diagnostic System connector.This connector is referred as "Mode select switch coupler" in the For Suzuki manuals. Unlike other gear indicators available for your bike,this product connects to the diagnostic connector. It makes the installation very simple.The unit reads data directly from the ECM, offering faster and more reliable readings than competitive products.The unit is fully automatic,there are no buttons and no "programming wire", The display will indicate all gears correctly when ignition is On,side stand is UP and the engine stop switch is in RUN position. Installation: Find the WHITE,6-pole male diagnostic connector,usually near the ECM box.It may have a black cap,or "dummy" female plug (without wires) attached to it.For GSF650 Bandit/For GSF1250;under right side frame cover, For DL650 ABS model;behind right side fuel tank cover , For VL1500/For Boulevard C90/For Intruder C1500;behind left frame head cover,Other models;under seat (rider or pillion) Remove the black cap or dummy female plug,and connect the plug.Route the cable to the mounting location.Peel off the green plastic from the back of the unit,and mount the display.Secure the cable with the cable ties supplied.The unit is fully functional after installation.there is no need to setup. Troubleshooting. Disconnect the connector and check whether the pins are broken,bent or pushed out of position.Reconnect the plug, and make sure that all connections are good and the connector is fully seated.Make sure the ignition is ON,side stand is UP and engine stop switch is in RUN position when you test the gear position indicator.If some gears are not indicated properly,most likely the Gear Position switch is defective,modified,or a box is installed.If the indicated gears are correct except under hard acceleration or braking,there is interference in the bike is wiring and the ECM receives incorrect gear position values from the sensor.This model indicates the gear position as known by the ECM. Package List: 1 x Motorcycle Speed Gear Display/Bracket (as shown in the option picture)
